The FAAC 415 230V motor is engineered for residential swing gates up to 4 meters wide, offering a smooth operation with a maximum rod speed of 16 mm/s. Designed with a power supply of 230V and a maximum force of 3000 N, it can accommodate an electric lock for gates up to 4 meters wide. This model is equipped with a rear attachment for easy installation and provides a high degree of safety with IP54 protection and thermal protection up to 140°C.
|
Model |
415 |
415 L |
|---|---|---|
|
Power supply voltage |
220-240V~ 50/60 Hz |
|
|
Electric motor |
Asynchronous single phase |
|
|
Max. power |
300 W |
|
|
Max expressed force |
3000 N (*) |
|
|
Rod max speed |
16 mm/s (*) |
|
|
Rod travel |
300 mm |
400 mm |
|
Max. leaf opening angle |
110° |
|
|
Operating ambient temperature |
-20°C ÷ +55°C |
|
|
Thermal protection |
140°C |
|
|
Protection class |
IP54 |
|
|
Weight |
7.8 Kg |
8 Kg |
|
Use frequency |
S3 – 30% |
|
|
Max. leaf width |
2.5 m (3 m with electric lock) |
3 m (4 m with electric lock) |
|
Mounting brackets |
Rear attachment to be welded/screwed – front attachment to be welded |
|
|
Dimensions (LxDxH) |
836 x 101 x 147 mm |
942 x 101 x 148 mm |
|
Electronic equipment |
Not included |
|
