The Centurion SDO5 SMART+ garage door opener combines quiet belt-driven operation with connected control for everyday home access. Suitable for sectional and tip-up doors, it comes in T10 and T12 models to suit different door sizes. Built-in Wi-Fi and Bluetooth support smartphone control and monitoring, while an integrated LED light illuminates the garage. Optional battery backup keeps access available during power cuts.
For simple, reliable garage door automation, enquire with Aero NZ today.
The Centurion SDO5 SMART+ garage door opener combines quiet belt-driven operation with connected control for everyday home access. Suitable for sectional and tip-up doors, it comes in T10 and T12 models to suit different door sizes. Built-in Wi-Fi and Bluetooth support smartphone control and monitoring, while an integrated LED light illuminates the garage. Optional battery backup keeps access available during power cuts.
For simple, reliable garage door automation, enquire with Aero NZ today.
Quiet everyday operation
A belt drive helps reduce operating noise, ideal for garages close to bedrooms and living spaces.
Connected door management
Built-in Wi-Fi and Bluetooth support smartphone control, door status monitoring and installer diagnostics.
Backup when you need it
An optional battery kit keeps the opener working during power cuts, with up to 70 operations depending on conditions.
Options for different doors
Choose the T10 for doors up to 12m² or the higher-output T12 for doors up to 15m².
Built-in garage lighting
An integrated LED courtesy light helps you see when entering or leaving the garage.
Obstruction detection and reversal
Adjustable electronic sensing detects obstructions and automatically reverses the door when required.
Specification | SDO5 SMART+ T10 | SDO5 SMART+ T12 |
Application | Residential sectional and tip-up garage doors | Residential sectional and tip-up garage doors |
Drive type | Belt drive | Belt drive |
Maximum door area | 12m² | 15m² |
Maximum door width | 6.5m, subject to door area and height limits | 6.5m, subject to door area and height limits |
Maximum push/pull force | 40kgf | 50kgf |
Maximum holding capacity | 1,000N | 1,200N |
Operator travel speed | Up to 9m/min, load dependent | Up to 9m/min, load dependent |
Motor voltage | 24V DC | 24V DC |
Rated motor power | 80W DC | 100W DC |
Mains input | 220–240V AC, 50/60Hz | 220–240V AC, 50/60Hz |
Transformer | 110VA thermally fused toroidal transformer | 150VA thermally fused toroidal transformer |
Battery backup | Optional kit, sold separately | Optional kit, sold separately |
Backup battery arrangement | 2 × 2.9Ah batteries | 2 × 2.9Ah batteries |
Battery charging rate | 870mA | 870mA |
Backup operation count | Up to 70, condition dependent | Up to 70, condition dependent |
Wireless connectivity | Bluetooth Low Energy and 2.4GHz Wi-Fi | Bluetooth Low Energy and 2.4GHz Wi-Fi |
Remote receiver | Code-hopping receiver | Code-hopping receiver |
Receiver frequency | 433MHz | 433MHz |
Remote storage | 30 four-button NOVA transmitters | 30 four-button NOVA transmitters |
Supplied remotes | 2 four-button transmitters | 2 four-button transmitters |
Wireless wall pendant | Optional, sold separately | Included |
Obstruction sensing | Hall Effect and current sensing, with adjustable sensitivity and automatic reversal | Hall Effect and current sensing, with adjustable sensitivity and automatic reversal |
Manual release | Carriage release cord | Carriage release cord |
Courtesy light | Integrated LED | Integrated LED |
Automatic closing | Adjustable; infrared safety beams required | Adjustable; infrared safety beams required |
Tamper detection | Built-in sensor | Built-in sensor |
Door-service monitor | Included | Included |
Door travel setting | Physical end-stops and automatic limit setup | Physical end-stops and automatic limit setup |
Accessory connections | 2 configurable I/O channels and 1 input | 2 configurable I/O channels and 1 input |
Safety beam compatibility | Wired or wireless | Wired or wireless |
Ingress protection | IPX0, indoor use | IPX0, indoor use |
Motor housing dimensions | 391mm L × 212mm W × 107mm H | 391mm L × 212mm W × 107mm H |
Compatible optional accessories | Battery backup kit, safety beams, keypads, NOVA remotes, SMART Siren and intercom systems | Battery backup kit, safety beams, keypads, NOVA remotes, SMART Siren and intercom systems |
Specification | Standard Sectional | Caravan Sectional | Tip-Up |
Maximum door height | 2,600mm | 3,206mm | 2,135mm |
Complete operator and rail length | 3,523mm | 4,130mm | 2,376mm |
Rail length | 3,193mm | 3,800mm | 2,046mm |
Maximum stroke length | 2,600mm | 3,206mm | 1,452mm |
