The Centurion V300 SMART+ swing gate motor automates single or double residential gates with a compact, low-profile actuator. It handles gate leaves up to 350kg at lengths up to 2 metres, with reduced weight limits for longer leaves. Battery backup maintains access during power cuts, while connected controls support smartphone monitoring. Adjustable automatic closing and partial pedestrian opening make everyday driveway access convenient.
For simple, reliable gate automation, enquire with Aero NZ today.
The Centurion V300 SMART+ swing gate motor automates single or double residential gates with a compact, low-profile actuator. It handles gate leaves up to 350kg at lengths up to 2 metres, with reduced weight limits for longer leaves. Battery backup maintains access during power cuts, while connected controls support smartphone monitoring. Adjustable automatic closing and partial pedestrian opening make everyday driveway access convenient.
For simple, reliable gate automation, enquire with Aero NZ today.
Compact swing gate automation
A low-profile actuator with a 300mm stroke suits shorter gate leaves and entrances with compatible pillar geometry.
Single or double gate options
Available in single and double kits, with inward- or outward-opening installation options to suit your entrance.
Access during power cuts
Battery-driven operation keeps your gates usable when mains power is interrupted.
Connected gate management
Built-in Wi-Fi and Bluetooth support gate monitoring and owner-approved remote installer diagnostics.
Convenient pedestrian access
Partial pedestrian opening provides access on foot without fully opening the driveway gates.
Flexible safety controls
Electronic obstruction sensing and support for wired or wireless safety beams help manage gate movement around the entrance.
Specification | V300 SMART+ |
Application | Single or double residential swing gates |
Maximum gate leaf weight | 350kg per leaf at lengths up to 2m and opening angles of 90° or 100° |
Maximum gate leaf length | 3m, with a maximum leaf weight of 230kg |
Published opening angles | 90° and 100°, subject to mounting geometry |
Opening direction | Inward or outward, with suitable mounting geometry |
Actuator stroke | 300mm |
Maximum push force | 250kgf |
Piston extension and retraction speed | Up to 28mm/sec, variable |
Typical full-stroke opening time | 11.3 seconds on a level gate with no wind |
Maximum daily operations | 250 |
Duty cycle with mains power | 50% at 25°C, without direct sun and with push force below 50% of rated force |
Motor voltage | 12V DC |
Mains input | 90–240V AC ±10%, 50/60Hz |
Battery arrangement | 1 × 12V battery; 7Ah in the feature panel and 7.2Ah in the technical table |
Battery charger output | 1.8A at 13.8V; charging current reduces to 1.2A at 90V AC input |
Mains current consumption | 170mA |
Maximum motor current | 15A per channel |
Controller | Vx SMART+ in a separate wallbox |
Wireless connectivity | Bluetooth Low Energy and 2.4GHz Wi-Fi |
Remote receiver | Built-in multichannel code-hopping receiver |
Remote storage | 1,500 remotes |
Receiver frequency | 433MHz |
Obstruction sensing | Electronic, with current sensing and optical position control |
Manual release | Key-operated release on each operator |
Automatic closing | Adjustable |
Pedestrian access | Partial opening |
Accessory connections | 3 inputs, 2 low-current I/O channels and 1 high-current output |
Safety beam support | Up to 3 sets of Photon SMART beams, plus independent wired opening and closing safety inputs |
Operator ingress protection | IP55 |
Wallbox ingress protection | IP65 |
Operator temperature range | −15°C to +50°C |
Retracted actuator length | 870mm |
Extended actuator length | 1,170mm |
Wallbox dimensions | 260mm W × 150mm D × 345mm H |
Minimum wall clearance at 90° or less | 200mm |
Maximum pillar thickness at 90° or less | 90mm |
Electric gate lock requirement | Required for gate leaves longer than 2.5m |
Compatible optional accessories | Safety beams, keypads, loop detectors, intercoms, SMART Siren, courtesy lighting and GLX900 electric gate lock |
Alternative power options | Solar supply and 16V AC low-voltage input with the appropriate components |
Gate Leaf Weight Limits
Gate leaf length | Maximum weight at 90° or 100° |
Up to 1.5m | 350kg |
Up to 2m | 350kg |
Up to 2.5m | 335kg |
Up to 3m | 230kg; electric gate lock required |
